【Scope of application】

It is used to change the color fastness of textiles, printing and dyeing, printing and other products after specific track rubbing.

【Standards compliant】

GB/T 29865-2013 Textiles Color fastness test Color fastness to rubbing small area method

AATCC 116 Color fastness to rubbing by rotating vertical tribometer method

ISO 105X16 Textile Color Fastness Test Part X16: Color Fastness to Rubbing-Small Area

【technical parameter】

1. Diameter of friction head: 16mm and 25mm

2. Provide pressure: 1134g

3. Working mode: clockwise rotation 1.125 rotations and then counterclockwise rotation

4. Speed range: 50～80 times/min

5. Counting range: 0～999999 times

6. Dimensions: 260×360×460mm

7. Weight: 15kg

8. Power source: AC220V 50Hz 100W
